Entrust Sigma DS2 Printer, Duplex, 125-Card Input Hopper is great for:
Types of cards
Government-issued IDs & Cards
Employee ID Cards
Student, Teacher, Faculty, & Admin ID Cards
Membership Cards
Guest Cards
Food Safe Labeling
Passenger Cards
Visitor ID Cards
Event ID Cards
Access Control Cards
Industries
Regional & Local Government
Enterprise
Education
Healthcare
Retail
Hospitality
Food Retail
Transportation
Standard Features:
Print Technology
Dye-sublimation / resin thermal transfer
Print Capabilities
Single or dual-sided
Print Resolution
300 dots per inch (dpi) (300 X 600, 300 X 1200)
Monochrome printing
Up to 880 single-sided cards per hour
Print Speed
Single-sided color ribbon – up to 225 cards per hour (cph)
Double-sided color ribbon – up to 140 cards per hour (cph)
Card Capacity
Input hopper – up to 125 cards
Output hopper – up to 25 cards (up to 100 optional)
Reject hopper – up to 10 cards
Card Sizes
Card input size:
Thickness – 0.010 inches to 0.040 inches
(0.25mm – 1.016mm)
Dimension – ID-1, CR-79, CR-80
Operating Environment
Temperature: 60°F to 95°F (15°C to 35°C)
Humidity: 20-80 % RH – non condensing
Physical Dimensions
L 17.4 in x W 8.9 in x H 9 in / 44.2 cm x 22.6 cm x 22.9 cm
Weight
12.1 lbs (5.49 kg); with options will vary
Connectivity
USB & Ethernet
Warranties
36 Months
Web browser support for Instant ID as a Service
Chrome – Preferred
Edge/Internet Explorer
Safari
Operating system support for printer driver
Windows 11
Windows 10 versions, 32- and 64-bit
Windows 8.1, 32- or 64-bit
Windows Server 2019
Windows Server 2016
Windows Server 2012, R2, 64-bit
Optional Features and Supplies
Magnetic Stripe Encoding
ISO 7811 three-track support (high- and low- coercivity)
JIS Type II Single-track option
WiFi
Wi-Fi types: 802.11g/n
Authentication modes: None, WPA2 Personal
Dual-band 2.4GHz & 5GHz
Smart Card Encoding
Single Wire or Loosely coupled:
Contact smart card encoding: ISO 7816 T=0 (T=1),
Class A 5V (3V and 1.8V)
Contactless smart card encoding:
ISO 14443 – A (B), ISO 15693, MiFare Series, DESFire Series,
HID IClass Series, HID Prox (125 KHZ)
Color Ribbons
Prefilled print ribbon cassettes:
YMCKT (500)
YMCKT-KT (350)
KTT (750)
ST-KT (500)
GT-KT (500)
Refill print ribbon kits:
YMCKT (250/500)
ymcKT (650)
YMCKT-KT (350)
ymcKT-KT (435)
KT (1000)
KTT (750)
YMCKF-KT (300)
YMCKL-KT (300)
